mopa laser marking machine
mopa laser marking machine
Specifications:

Device model: FL-MP20, FL-MP30, FL-MP60

Laser power: 20W / 30W, 60W

Laser wavelength: 1064nm

Beam quality (M2): ≤1.5 /≤1.8

Laser repetition frequency: 20 ~ 200KHz

Marking range: 110 × 110, 170 × 170, 220 × 220 (mm)

Maximum linear speed: 9000mm / s

Minimum line width: 0.03mm

Minimum character: 0.15

Cooling method: air cooling

Total power consumption: 550W, 700W, 900W

Power demand: 220V / 50Hz

Appearance size: 680 × 780 × 1450mm

Feature description

1. The beam quality is good, close to the diffraction limit, so that more precise marking can be achieved; the processing heat affected area is small;

2. Adopt pulse width adjustable mode, pulse width and frequency can be adjusted independently, pulse shape can be controlled, and parameter adjustable range is large;

3. The aluminum material can be directly printed with a black effect, and the marking place is smooth and free of uneven marks;

4. The electro-optic conversion rate is as high as 30%, and the power consumption is about 10% of the traditional model;

5. It is cooled by air cooling, and the whole machine is compact;

6. No consumables, maintenance-free, and long service life;

7. It can achieve constant peak power output and higher processing efficiency;

8. The laser output power is stable and the reliability is high, which meets the production needs of continuous and stable processing for 24 hours;

9. The marking is fine, beautiful and durable.



Application area

Mainly used for aluminum alloy and anodized aluminum black marking, aluminum oxide sheet surface stripping, electronic and ITO precision processing, stainless steel color marking and other sensitive materials marking, suitable for marking most metal and non-metal materials.

Sample show
